【linux】iptables和ufw禁用IP和端口

引言

有时候服务器，为了安全需要，会限制某些ip和端口对服务器的访问。那具体该如何配置呢？本文带你解决。

禁用IP和端口

1、方法1：iptables

iptables v1.8.4
Usage: iptables -[ACD] chain rule-specification [options]
       iptables -I chain [rulenum] rule-specification [options]
       iptables -R chain rulenum rule-specification [options]
       iptables -D chain rulenum [options]
       iptables -[LS] [chain [rulenum]] [options]
       iptables -[FZ] [chain] [options]
       iptables -[NX] chain
       iptables -E old-chain-name new-chain-name
       iptables -P chain target [options]
       iptables -h (print this help information)
Commands:
Either long or short options are allowed.
  --append  -A chain            Append to chain
  --check   -C chain            Check for the existence of a rule
  --delete  -D chain            Delete matching rule from chain
  --delete  -D chain rulenum
                                Delete rule rulenum (1 = first) from chain
  --insert  -I chain [rulenum]
                                Insert in chain as rulenum (default 1=first)
  --replace -R chain rulenum
                                Replace rule rulenum (1 = first) in chain
  --list    -L [chain [rulenum]]
                                List the rules in a chain or all chains
  --list-rules -S [chain [rulenum]]
                                Print the rules in a chain or all chains
  --flush   -F [chain]          Delete all rules in  chain or all chains
  --zero    -Z [chain [rulenum]]
                                Zero counters in chain or all chains
  --new     -N chain            Create a new user-defined chain
  --delete-chain
            -X [chain]          Delete a user-defined chain
  --policy  -P chain target
                                Change policy on chain to target
  --rename-chain
            -E old-chain new-chain
                                Change chain name, (moving any references)
Options:
    --ipv4      -4              Nothing (line is ignored by ip6tables-restore)
    --ipv6      -6              Error (line is ignored by iptables-restore)
[!] --protocol  -p proto        protocol: by number or name, eg. `tcp'
[!] --source    -s address[/mask][...]
                                source specification
[!] --destination -d address[/mask][...]
                                destination specification
[!] --in-interface -i input name[+]
                                network interface name ([+] for wildcard)
 --jump -j target
                                target for rule (may load target extension)
  --goto      -g chain
                              jump to chain with no return
  --match       -m match
                                extended match (may load extension)
  --numeric     -n              numeric output of addresses and ports
[!] --out-interface -o output name[+]
                                network interface name ([+] for wildcard)
  --table       -t table        table to manipulate (default: `filter')
  --verbose     -v              verbose mode
  --wait        -w [seconds]    maximum wait to acquire xtables lock before give up
  --wait-interval -W [usecs]    wait time to try to acquire xtables lock
                                default is 1 second
  --line-numbers                print line numbers when listing
  --exact       -x              expand numbers (display exact values)
[!] --fragment  -f              match second or further fragments only
  --modprobe=          try to insert modules using this command
  --set-counters PKTS BYTES     set the counter during insert/append
[!] --version   -V              print package version.

• 🈲端口

  iptables -A INPUT -p tcp --dport 80 -j DROP
  iptables -A INPUT -p tcp --dport 5053 -j DROP


  • 🈲IP

    iptables -I INPUT -s 10.115.10.129 -j DROP


    • 保存配置

      sudo service iptables save

      实测这条命令行不通，报错：iptables: unrecognized service

      下面这条可以

      sudo iptables-save


      2、方法2：ufw

      UFW (Uncomplicated Firewall)是Ubuntu 自带的防火墙配置工具 。UFW 是一个用来管理 iptables 防火墙规则的用户友好的前端工具。它的主要目的就是为了使得管理 iptables 更简单。

      Usage: ufw COMMAND
      Commands:
       enable                          enables the firewall
       disable                         disables the firewall
       default ARG                     set default policy
       logging LEVEL                   set logging to LEVEL
       allow ARGS                      add allow rule
       deny ARGS                       add deny rule
       reject ARGS                     add reject rule
       limit ARGS                      add limit rule
       delete RULE|NUM                 delete RULE
       insert NUM RULE                 insert RULE at NUM
       route RULE                      add route RULE
       route delete RULE|NUM           delete route RULE
       route insert NUM RULE           insert route RULE at NUM
       reload                          reload firewall
       reset                           reset firewall
       status                          show firewall status
       status numbered                 show firewall status as numbered list of RULES
       status verbose                  show verbose firewall status
       show ARG                        show firewall report
       version                         display version information
      Application profile commands:
       app list                        list application profiles
       app info PROFILE                show information on PROFILE
       app update PROFILE              update PROFILE
       app default ARG                 set default application policy


      Ubuntu安装完毕，默认没有启动ufw。所以如果直接运行上述语句，那么它启动后就会使用默认规则，禁止一切流量，包括SSH的22端口，如果本来就是在SSH上远程操作，那么悲剧了，所以要先启用SSH的端口（默认是22，如果你设置了其他端口就加上去）

      sudo ufw allow 22
      sudo ufw reject 80 #(拒绝，直接返回：Connection refused）
      sudo ufw deny 5053 #(否认，过段时间后返回：Connection timed out）
      sudo ufw enable
      sudo ufw status


      • 查看ufw防火墙是否在工作，查看使用中的规则

        ufw status


        • 启动/关闭/重置ufw防火墙

          ufw enable
          ufw disable
          ufw reset


          • 允许其它主机访问本机21端口，协议包含tcp和udp

            ufw allow 21


            -允许其它主机使用tcp协议访问本机80端口

            ufw allow 80/tcp


            • 可以使用in或out来指定向内还是向外。如果未指定，默认是in

              允许访问本机http端口

              ufw allow in http


              • 禁止其它主机访问本机80端口，

                • reject，直接告诉拒绝，返回的提示信息更多，比如ssh该主机时，直接返回：Connection refused

                • deny，否认，返回的提示信息少，比如ssh该主机时，过段时间后才返回：Connection timed out

                  ufw reject 80


                  ufw deny 80


                  • 禁止本机对外访问192.168.1.1

                    （实测有用）

                    ufw deny out to 192.168.1.1


                    • 禁止192.168.1.1对内访问本机

                      （实测没用）

                      ufw deny from 192.168.1.1


                      • 删除规则，只要在命令中加入delete就行了

                        ufw delete deny 80/tcp


                        • 打开/关闭log

                          ufw logging on
                          ufw logging off


                          logging on后 默认是low 等级。ufw支持多个等级： ‘low’, ‘medium’, ‘high’ and ‘full’。简单说low记录事件做少，其他等级记录逐级增加。使用默认的low level就够了。log文件保存在/var/log/ufw.log 文件内，可以用tail -n COUNT file的形式显示最后几行
